KAPA 30HP/22kW Rotary Screw Air Compressor, 123CFM @116PSI, 480V/60Hz/3-Phase, paired with 22kW Refrigerated Dryer (220V/60Hz/1-Phase). Ideal for heavy-duty stationary industrial use.
Product details
| Management number | 222690565 | Release Date | 2026/05/04 | List Price | US$3,959.60 | Model Number | 222690565 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
KAPA 30HP / 22KW Rotary Screw Air Compressor – Heavy-Duty Industrial Solution The KAPA 30HP / 22KW rotary screw air compressor delivers 123 CFM at 116 PSI with a 480V / 60Hz / 3-phase motor, providing reliable, continuous airflow for pneumatic tools, machinery, and production lines. Its heavy-duty design with robust components ensures long-term durability and reduced maintenance, while the built-in oil separator delivers clean compressed air, protecting equipment and improving efficiency. The stationary base mount offers stability, reduces vibration and noise, and allows easy installation in workshops or industrial facilities. Energy-efficient operation minimizes power consumption, and the compressor adapts to varying pressures and air demands, making it suitable for manufacturing, automotive, construction, and other heavy-duty industrial applications. With easy maintenance and reliable safety features, it is a durable, versatile, and cost-effective choice for continuous industrial compressed air needs.
- Specifications: Power: 30HP / 22KW; Voltage: Input Voltage (V/Hz): 480V / 60Hz; Electrical Phase: 3ph; Air Flow: 125-113 cfm; Output Pipe Diameter: G1"; NPT 1"; Maximum Operating Pressure: 125psi / 8-10 bar; Full-Load Amps: 69 Power: 30HP Refrigerated Dryer; Input Voltage (V/Hz): 220V / 60Hz; Electrical Phase: 1ph; Air Flow: 140.59 cfm; Maximum Operating Pressure: 102psi-232psi
- Characteristics : Air Cooling Belt Driven / Direct Driven Stationary Screw Air Compressor, Built-in Air Oil Separator , Motor RPM: 3000;All the compressors we produced are qualified for CE certificated
- Rotary Screw Air Compressor: KAPA compressors are used safely in all applications of all small and medium sized businesses,we help drive your profitability by lowering your total cost of ownership while providing you with the performance and reliability that you have come to expect from KAPA compressors
- Advantages: The KAPA series rotary screw compressor operates without the elevated vibration and sound levels normally associated with typical piston compressors,KAPA compressors feature a small footprint and are built to provide exceptional reliability and extremely low maintenance
- Application: KAPA provide one- stop solution. We can not only provide the air compressor, but also high quality air treatment equipment, such as air dryer, air filter and air compressor spare parts. We are more than a factory but a trustworthy air compressor solution provider
| Color | Green+white |
|---|---|
| Noise | 72 Decibels |
| Style | Horizontal |
| Voltage | 480 Volts |
| Brand Name | kapa |
| Model Name | KQ22-8-480V VSD+TP-22 |
| Unit Count | 493.0 Count |
| Item Weight | 493 Kilograms |
| Manufacturer | KAPA |
| Model Number | KQ22-8-480V VSD+TP-22 |
| Power Source | ac |
| Material Type | Cast Iron |
| Maximum Power | 22 Kilowatts |
| Maximum Pressure | 116 Bars |
| Motor Horsepower | 30 Horsepower |
| Air Flow Capacity | 123 Cubic Feet Per Minute |
| Maximum Horsepower | 30 Horsepower |
| Additional Features | Heavy Duty |
| Included Components | 22 kW Refrigerated Air Dryer × 1 unit, 22 kW Screw Air Compressor × 1 unit |
| Manufacturer Part Number | KQ22-8-480V VSD+TP-22 |
| Item Dimensions L x W x H | 49.21"L x 31.89"W x 44.88"H |
| Recommended Uses For Product | Bolting, Cutting, Drilling, Grinding, Spraying |
