ENERMAX Revolution D.F. X ARGB ATX3.0 PCI-e 5.0 Compact Gaming & Streaming PC Power Supply 850W 80Plus Gold (Fully Modular, 2X 12VHPWR, Semi-Fanless), ERT850EWT

REVOLUTION D.F. X rounds off the REVOLUTIONs series and is primarily aimed at gamers and content creators. In addition to a native 12VHPWR cable for the obligatory Intel ATX 3.0 and PCIe 5.0 standard, it offers another dual 8pin to 12VHPWR additional cable for connecting an additional graphics card or for future OC graphics cards that require two 12VHPWR connections. The connections already have the "4-spring design" recommended by Intel®. Like the REVOLUTION D.F. 2 is the REVOLUTION D.F. X also a compact, fully modular power dwarf with an overall depth of only 14 cm. The 80 PLUS® Gold certified power supply series is equipped with the patented DFR™ (Dust Free Rotation) technology. This prevents dust accumulation on the fan blades and guarantees a clean and durable power supply. The decision to only use 100% Japanese 105°C electrolytic capacitors guarantees high manufacturing quality and a long-lasting product. Based on an advanced Half Bridge LLC resonant converter and DC-to-DC circuit, the power supply is able to deliver perfect voltage regulation and very stable output power. The extremely stable single +12V rail, which has up to twice the maximum output power for a short time, allows high current peaks of the high-performance processors and graphics cards without the system having to be switched off directly. Sufficient protection is nevertheless guaranteed by OVP, UVP, OPP, SCP and OTP. The intelligent semi-fanless control keeps the power supply fan in passive mode up to a load of 20%. The FDB (Fluid Dynamic Bearing) silent fan is equipped with a 6-pole, 3-phase motor and high-pressure fan blades to generate extremely high air pressure while ensuring excellent running smoothness. In addition, anti-vibration dampers on the fan frame offer a reduction in fan vibration. The ARGB side panel with 14 built-in RGB lighting modes can be operated "stand-alone", controlled via the supported motherboard sync or switched off via the ON/OFF button.

• Patented DFR (Dust Free Rotation) technology: Reduces dust accumulation on the fan blades by turning the fans backwards for a few seconds after starting the power supply to remove the accumulated dust. This prevents long-term dust deposits. After that, it returns to normal passive operation.
• IntelATX3.0 & PCIe 5.0 Ready: Full compatibility with the latest IntelATX3.0 power supply specifications & PCIe 5.0 Ready with native 12VHPWR cables. Connections of the 600W 12VHPWR cables with Intel recommended "4-spring design".
• Intelligent semi-fanless control: Fluid Dynamic Bearing silent fan with 6-pin 3-phase motor and high-pressure fan blades to ensure extremely high air pressure while maintaining excellent smoothness. Anti-vibration dampers on the fan frame reduce fan vibration. Completely silent up to a system load of 20%. Only then does the 12cm FDB fan ensure continuous quiet cooling.
• Superior performance: highly efficient LLC resonant converter and DC to DC circuit design for higher output efficiency and voltage stability; extremely stable single +12V rail which has up to 2x maximum output power in the short term; sufficient protection guaranteed by OCP, OVP, UVP, OPP, SCP and OTP
• 80Plus Gold Energy Saving Certificate: More than 92 percent efficiency in the 230 volt grid with a load of 20 to 100 percent. Extremely compact housing design with only 14 cm depth suitable Revolution D.F. X excellent for compact gaming & streaming PCs.
